Synthetic braiding 8-stranded rope







Circle Diameter PP Dan Line Polyethylene Polyamide (nylon) Polypropylene (tape yarn)
weight, 220м breaking load weight, 220м breaking load weight, 220м breaking load weight, 220м breaking load
мм мм inch kg tons kg tons kg tons kg tons
100 32 1  1/4 101 13,50 115 10,7 139 20,00
115 37 1  1/2 129 16,93 145 13,40 176 24,90
125 40 1  19/32 158 20,51 173 16,30 218 30,00
150 48 1  7/8 229 28,61 253 22,80 312 42,00
157 50 ~2 248 29,30 275 24,30 339 45,40
175 56 2  1/4 312 37,86 345 30,40 425 56,00
200 64 2  1/2 407 48,98 451 39,10 554 72,00
225 72 2  7/8 515 61,50 570 49,10 702 90
250 80 3  1/4 638 75,64 706 60,40 867 110
275 88 3  1/2 772 90,77 853 72,50 1049 131
